Technical Data

The number of axes	3
Umlaufdurchmesser über dem Bett - mm	1140
Max. Drehdurchmesser - mm	750
Max. Drehlänge - mm	5050
Max. diameter bites. rods - mm	164
The spindle speed - rpm/min	1500
Spindle Motor Power - kW	75
Number of tools	12
Travel Axis X - mm	400
Travel Axis Y - mm	200
Travel Axis Z - mm	5100

---
